FXC7000 AC-DC Series Data Sheet
FXC7000 OVERALL SIZE: 15.17" x 8.00" x 5.00" (385.3mm x 203.2mm x 127.0mm)
3.510"
7.705"
(195.7mm)
10.260"
(260.6mm)
15.17"
(385.3mm)
1.10"
(27.9mm)
MAINTAIN 25 SQ IN MIN
FREE AREA (FRONT AND
0.955"
(24.3mm)
(89.2mm)
0.85"
(21.6mm)
REAR) FOR AIR COOLING
A
A
A
A
6.850"
(174mm)
INSULATOR
5.42"
(137.7mm)
4.24"
(107.6mm)
<--AIRFLOW
SIDE VIEW
BLOCK
A
A
A
A
1.100" (27.9mm)
0.53"
(13.4mm)
2 PL
3.60"
4.480" (91.5mm)
0.480"
(12.2mm)
A
A
A
A
FOR MOUNTING, USE M4 X 0.7 SCREWS,
8PL (MARKED A) ON SIDE OR BOTTOM
(113.8mm)
2 PL 1.22"
WITH MAXIMUM PENETRATION 3.8mm.
(31.1mm)
BOTTOM VIEW
RECOMMENDED MOUNTING TORQUE
10.5 INCH LBS. (0.64N/M)
A 0.955"
A
A
A
(24.3mm)
2 PL
DIA 0.25"
(6.4mm)
0.70" 2 PL
(17.9mm)
1.10" 2 PL
(28mm)
3.510"
(89.2mm)
7.705"
0.20"
(5.1mm)
REAR VIEW
(195.7mm)
13.455"
(341.8mm)
FRONT VIEW
9
18
26
1
10
19
5.00"
(127mm)
PE
AC INPUT
M4 THREAD
0.06 (1.7) 2 PL
VOLTAGE ADJUST POT
DC OUTPUT
POS
NEG
L1
L2
L3
13mm CENTER-TO-CENTER
10mm
26-PIN CONNECTOR
8.00"
(203.2mm)
AMP PN: 749030-1
PIN 1
INPUT VOLTAGE RANGE
5 LED INDICATORS
AC
DC Vadj
SIGNAL
MATING CONNECTOR:
SELECT MODULE
ROTATE 180 DEGREES FOR 240 VAC
T
CONNECTOR SHELL...
AMP PN 748365-1
CONTACTS...
AMP PN 748333-2
INPUT VOLTAGE
DISPLAY CUTOUT
4 8 0VAC
AUG 18, 2006 revised to JAN 09, 2007
Page 4 of 4
www.power-one.com
